Agilent N6741B, DC Power Module, 5V, 20A, 100W

Unit is tested and in good working and cosmetic condition, please see pictures!

2 pcs available.

Condition: Tested good

Need calibration for the unit? Please contact us and we'll send you a affordable calibration quote!

General description (Retrieved 07/2024, Keysight)

Note:  Unit specific features depend on installed options. Please see unit pictures for options!

Highlights

Output ratings

• Voltage: 5 V

• Current: 20 A

• Power: 100 W

Programming accuracy (at 23°C ±5°C)

• Voltage: 0.1% + 19 mV

• Current: 0.15% + 20 mA

Ripple and noise (20 Hz to 20 MHz)

• Voltage rms: 2 mV

• Voltage peak-to-peak: 11 mV

• Current rms: 8 mA

The Keysight N6741B is a 100 W basic DC power module that provides programmable voltage and current, measurement and protection features at a very economical price, making these modules suitable to power the DUT or to provide power for ATE system resources such as fixture control.

This module is used in both the small, multiple output 1U high N6700 Low-Profile Modular Power System (for ATE systems) and the multiple output N6705 DC Power Analyzer (for bench testing). GPIB, LAN, USB, and LXI compliance are standard. Select from more than 20 different DC power modules, ranging in capability from basic to high precision, and in power from 20 - 500 W.

Please contact us for the unit's datasheet!
